Long-range and lightweight. The secure, lightweight real-time airborne laser scanner.
The Teledyne OPTECH EchoONE is a secure lightweight airborne laser scanner compatible with UAVs such as the DJI M300/M350, Freefly Astro, Inspired Flight IF800, WISPR Skyscout, and others. For applications such as land surveying, electric utility vegetation management and asset management, and transportation projects, the EchoONE delivers secure, colorized engineering-grade lidar point clouds.
EchoONE weighs just 1.2kg and can be operated from smaller UAVs such as the Freefly Astro, Inspired Flight IF800 and DJI M300/M350, while operating reliably at a regulatory limit of 120m / 400ft agl delivering an accuracy of up-to 1.5cm RMSZ, ranging precision of 5mm and 0.5mrad 1/e2 beam divergence resulting in clean and precise point clouds.
NDAA compliant and affordable
EchoONE is designed and manufactured in compliance with the latest NDAA requirements ensuring data security while competitively priced to less secure options.
Full undecimated georeferenced point clouds generated in real-time allowing infield verification combined with rapid post-processing through RESEPI’s “one-click” PC-Master Pro post-processing solution. Full-featured post-processing available with Teledyne Geospatial LMS Professional.
270 m range to 20% reflectivity targets
Up to 8 returns per pulse
90 deg × 20 deg field of view
4 unique vertical scan angles
5 mm lidar ranging precision
1.5 cm georeferenced vertical accuracy
EchoONE is 1.2kg
Integrated 5MP global shutter camera
Optional 61MP camera
Inertial Labs KERNEL-210 tactical grade IMU
| Brochures | |
|---|---|
| EchoONE Brochure | View and Download the EchoONE brochure. |
